3. Hardware
3.1. Connectors (BPSG 4 and BPSG 6)
Front view:
Backview:
Power Supply Connector
Status LED
10MHz Reference clock
input (max 3,3V; optional)
Charge
-
LED
ON/OFF Switch
USB Connector
(no charging
capability)
RF Output
