HW © 2015 Aaronia AG, DE-54597 Strickscheid, www.aaronia.com, mail@aaronia.de
17
Manual RF Signal-
Generator
(8) For advanced users only: shows the device-specific translation of the program. This
function is not required for operation.
(9) Writes the current settings to the device.
6.4.2. Program Modes
6.4.2.1. Sweep
Figure: SW-06
Uniformly runs through a frequency range from start to stop. If no increment is specified, then
the smallest possible increment is selected.
Since Start and End Power can be set separately, you can also run a Power Ramp or both
simultaneously.
6.4.2.2. Constant Wave
Figure: SW-07
Selects a frequency and a level for the selected time.
