Services Reserved for Attendants
MD Evolution – Dialog 4425 IP Vision202
Select Press the dynamic function key shown on the left.
You extension then prompts you to define the number for the
selected abbreviated number, or if it is already defined, it displays
the abbreviated number, which you may subsequently modify or
erase, as necessary.
COMPLETE NO z Dial the external number associated with the selected
abbreviated number.
It may contain up to 18 digits; the number entered should not contain
an external network access prefix. Generally speaking, it should be
entered comprehensively.
Þ Press the dynamic function key shown on the left.
ABBR. NAME z On your position’s keypad, enter the name identifying the
abbreviated number.
This name, from 1 to 15 characters, will allow users to clearly identify
an abbreviated number. It will then also be included in your
company’s directory; as a result, a call by name may be placed to
any external party included in the abbreviated dialling list. See also
the “Directory, Phone Book and Call List” section.
The letters are entered by repeatedly pressing your extension’s
keypad keys; the “1” key is used to enter a space, dash and other
punctuation marks; pressing the “*” key toggles between upper-
case and lowercase characters.
SHORT NUMBER CONFIGURATION
List number: 1
Short number: 5
External number: < 0164477500 >
Name: < ERICSSON >
Trunk: <1>
Options ÛÞ Select
SHORT NUMBER CONFIGURATION
External number: < 0164477500 >
Name: < ERICSSON >
Trunk: <1>
Completed (0-1): <1>
NEXT BACK
Options ÛÞ Select
