205MD Evolution – Dialog 4425 IP Vision
Services Reserved for Attendants
TK GROUP NO z Dial the number for the involved trunks group.
To do so, use your extension’s keypad, holding each key down for
approximately 2 seconds, or use the “Erase” option to cancel the
last character entered.
This number corresponds to the external network for which you
wish to obtain the incoming calls service quality information.
Generally, you need to enter the value “1”, which corresponds to
the public network trunks group. The alternative values are from “2”
to “8”.
Þ Press the dynamic function key shown on the left.
PERIOD NO z Make your observation period selection, either “0” or “1”.
Value “0” corresponds to the period elapsed since the last time the
traffic counters were reset to zero. Value “1” corresponds to a pre-
defined selected period.
Þ Press the dynamic function key shown on the left in order to
have the “OK” option highlighted.
The dynamic option “Erase” becomes “Select”.
Select Press the dynamic function key shown on the left.
According to the previous selection, the results are displayed as
illustrated in one of the screens that follow; the first indicates the
date of the last traffic counter reset, the other the pre-defined
observation period.
The number of incoming calls received from the external network
identified by its trunks group number is displayed in a 5-digit format;
if that number exceeds those place values, it will be followed by
asterisks (*).
The percentage of calls lost varies between 0 and 99%.
INCOMING CALLS STATS BY TRUNK
Incoming calls stats. since the 15/03/2008 - 18:30.
For trunk 1, 13% of calls lost for 8320 calls
received.
BACK
Options ÛÞ Select
