AAT SOLO - Disassembly; Removing Drive Wheels; Removing the Operating Unit; Removing the Battery Pack

25
7 Disassembly
Remove drive wheels
Remove the operating unit
Carry out the steps listed in chapter 5.4 in reverse order.
Remove the anti-tip supports
Flip the release .
Turn the release. Remove the drive wheel.
Repeat process on the other
side.
Remove the battery pack
Carry out the steps listed in chapter 5.2 in reverse order. Please note that the ight mode (crossed-out
ash) is set for the lithium-ion battery pack.
Pull out the locking bolts. Remove the anti-tip supports. Repeat process on the other
side.
i
Loosen the screws. Turn and insert the safety
edge. Note the arrow!
Tighten screws.
