ABAC FORMULA Series - Performance and Specifications; General Data; Compressor Rating Data

P. 24 - Chap. 4 Performance and specifi cations
G
B
4
Performance and
specifi cations
4.1
General data
-
Model Pressure
Motor
power
Air end Capacity Oil Weight Dimensions
Noise
levels*
bar kW m
3
/min Kg Kg mm dB(A) - L
p
(A)
Base 270 l 500 l
5.5
8
5.5 BA51
0.78
7
270
+
28
dryer
355
+
28
dryer
414
+
28
dryer
1030 x 615 x 1045
1180 x 600 x 1645
(Genesis 270 l.)
1960 x 600 x 1645 (Genesis 500 l.)
66
10 0.69
13 0.54
15 0.40
7.5
8
7.5 BA51
1.20
7
275
+
28
dryer
360
+
28
dryer
419
+
28
dryer
1030 x 615 x 1045
1180 x 600 x 1645
(Genesis 270 l.)
1960 x 600 x 1645 (Genesis 500 l.)
68
10 1.04
13 0.80
15 0.64
11
8
11
BA51
1.65
7
275
+
32
dryer
360
+
32
dryer
419
+
32
dryer
1030 x 615 x 1045
1180 x 600 x 1645
(Genesis 270 l.)
1960 x 600 x 1645 (Genesis 500 l.)
69
10 1.40
13 1.17
15 0.95
15
8
15 BA51
2.01
7
300
+
32
dryer
385
+
32
dryer
444
+
28
dryer
1030 x 615 x 1045
1180 x 600 x 1645
(Genesis 270 l.)
1960 x 600 x 1645 (Genesis 500 l.)
69
10 1.72
13 1.49
15 1.16
15
8
15 BA69
2.32
7
286
+
32
dryer
371
+
32
dryer
430
+
32
dryer
1030 x 615 x 1045
1180 x 600 x 1645 (Genesis 270 l.)
1960 x 600 x 1645 (Genesis 500 l.)
69
10 1.93
13 1.62
15 1.30
± 3 dB(A) to standards PNEUROP/Cagi
4.2
Compressor rating data
A metal plate TM indicating the compressor specifi cations is
applied to the machine: fi gure 25 shows the position
Fig. 25
TM
PF
