P. 34 - Chap. 6 Handling and installation
G
B
38 remote control digital INPUT terminal
LOAD/NO-LOAD remote control
(see paragraph 7.4.2.3 - Remote control type)
The switch must be connected to the following terminals after removing the jumper:
3 digital INPUT common terminal
38 remote control digital INPUT terminal
ON/OFF - LOAD/NO-LOAD remote control
(see paragraph 7.4.2.3 - Remote control type)
Two switches must be used for this configuration.
The switches must be connected to the terminals after removing the jumper:
ON/OFF SWITCH
3 digital INPUT common terminal
38 remote control digital INPUT terminal
LOAD / NO-LOAD START SWITCH
3 digital INPUT common terminal
39 remote control digital INPUT terminal
Following modifications to the wiring, the remote control must be configured as explained in paragraph
7.4.2.3 - Local/remote /program control - Remote control type
