ABB 2600T Series Operating Instruction

64 OI/266CXX/266JXX/HART-EN Rev. B | 266CRx, 266JRx, 266CSx, 266JSx
Error code Displayed message Possible cause Recommended measure Transmitter
reaction
F109.003
Process Temperature
Sensor Fail
A/D converter error of the temperature
sensor.
Check the connection of the temperature
electronics. Temperature electronics must
be replaced if the problem persists.
Alarm
current
Wire break of wrong Pt100 connection. Check the Pt100 connections and process
conditions.
The reference voltage for the temperature
measurement is not correct.
The PCB for the temperature measurement
should be replaced.
The difference between the main channel
and the reference measurement is outside of
tolerance.
F110.002
Sensor Temperature Fail Error in the current circuit for scanning the
temperature.
The measuring cell must be replaced. Analog
alarm signal
F112.001
Static Pressure Sensor Fail Error in the current circuit for scanning the
static pressure.
The measuring cell must be replaced. Analog
alarm signal
F114.000
P-dP Sensor Fail Mechanical damage on the measuring cell.
Measuring cell loses filling fluid, diaphragm is
torn, sensor damaged.
The measuring cell must be replaced. Analog
alarm signal
F116.023
Electronic Memory Failure Electronic memory is damaged. The electronics must be replaced. Analog
alarm signal
F118.017
Sensor Memory Fail Measuring cell memory damaged. The measuring cell must be replaced. Alarm
current
F120.016
Sensor Invalid The measuring cell signal is not updated
correctly due to an electronics error, a
measuring cell error or a poorly connected
measuring cell cable.
Check the cable connection and replace
measuring cell if the problem persists.
Analog
alarm signal
The model / the version of the measuring cell
is no longer compatible with the connected
version of the electronics.
The measuring cell must be replaced.
M014.037
Configuration Error See the operating manual for possible cause
of the error.
Use HART configurator (DTM – handheld
terminal) to correct the configuration.
None
M016.039
PILD-Changed Op.
Conditions
The process conditions have changed to
such an extent that new settings are required
for the PILD algorithm.
New training is required for this new
process condition.
None
