ABB 630 series - Page 54

+
-
DIFF
G
mA
Shunt
IN +
IN -
GND
Temperature
Sensor/
Resistor
GUID-4A3E0061-DFDF-4F03-98B7-2CE2779D6A4E V1 EN
Figure 27: Two-wire connection RTD sensors and resistance
+
-
DIFF
G
mA
Shunt
IN +
IN -
GND
GUID-C06784EE-0A4F-47F1-9485-F1E3A83D248C V1 EN
Figure 28: Current connection
+
-
DIFF
G
mA
Shunt
IN +
IN -
GND
GUID-649FA427-3F38-4364-991F-362B20CCAD57 V1 EN
Figure 29: Voltage connection
Section 5 1MRS755958 C
Connecting
46 630 series
Installation Manual
