Section 8 Technical data
8.1 Case and HMI display variants
8.1.1 Front side of the IED
GUID-5CFD3446-A92F-4A5F-B60D-90025DCFDC61 V2 EN
Figure 33: Front view of 4U half 19” IED
The LHMI includes a monochrome LCD of 320x240 pixels.
1MRS755958 C Section 8
Technical data
630 series 67
Installation Manual
