Technical Data Appendix A Hardware Units
142 3BSE 027 941 R301
Modem support Yes
COM4 Serial Communication
Communication speed 9600 baud
Signal levels RS232-C
Connector RJ45
Modem support No
Electrical ModuleBus
I/O capacity 1 x S800 I/O base cluster with up to 12 x S800 I/O units.
Supply current • Max 24 V – 1.0 A (short circuit proof, fuse 2A fast)
• Max 5 V – 1.5 A (short circuit proof)
Supply voltage variation 24 V – follows the input power at L+
Optical ModuleBus
I/O capacity up to 7 x S800 I/O clusters each with 12 units
Connector • Duplex Fiber Optic Cable
• Simplex Fiber Optic Cable
CEX-bus
Capacity up to 12 communication interfaces
Supply current Max 24 V – 2.4 A (fuse 3.15 A fast)
Table 32. PM856/PM860 and TP830 Interfaces – Technical data (Continued)
