Section 2 Installation Installing the PM8xx/TP830 Processor Unit in Single Configuration
3BSE 027 941 R301 59
Figure 14. TB851 Terminator for CEX-bus (female)
F
R
Rx/Tx
RTS
CI851
F
R
Rx/Tx
CI852
F
R
Tx1
Rx1
Tx2
Rx2
CI853
COM1 COM2
F
R
Rx/Tx
CI852
F
R
Tx1
Rx1
Tx2
Rx2
CI853
COM1 COM2
F
R
Tx1
Rx1
Tx2
Rx2
CI853
COM1 COM2
TK850 Cable
CPU unit
Terminator
TB851
