ABB AC 800M

Installing the PM8xx/TP830 Processor Unit in Single Configuration Section 2 Installation
58 3BSE 027 941 R301
Figure 13. TB850 Terminator for CEX-bus (male)
A TB850 male CEX-bus termination unit is supplied with each package
(PM856K01, PM860K01, PM861K01 and PM864K01) of the PM8xx/TP830
processor unit.
F
R
Rx/Tx
RTS
CI851
F
R
Rx/Tx
RTS
CI851
Terminator
CPU unit
TB850
