ACH 500 Programming Manual A-1
Appendix A – Complete Parameter Settings
The tables in this appendix list all the parameters and alternative settings for
the ACH 500. Use these tables as reference guides when you are customizing
macros for your ACH 500 application. A signal flow diagram is included at
the end of this appendix.
Table A-1 Parameter Settings
Parameter Alternative Settings
Custom
Setting
START-UP DATA
A LANGUAGE ENGLISH; GERMAN; ITALIAN; SPANISH; DUTCH; FRENCH; DANISH;
FINNISH; SWEDISH
B APPLICATIONS HVAC; FLOAT PT.; HVAC-PI; P&F AUTOM; USER load; USER save
C APPLIC. RESTORE NO; YES
D SUPPLY VOLTAGE 208/220/230/240; 440/460/480/500
E USER DISPLAY SCALE 0 – 10000
F MOTOR CURRENT -FLA 0 A – 1000 A (printed on the motor nameplate)
G MOTOR POWER hp (kW) 0.7 HP – 1340 HP (0.5 kW – 1000 kW) (printed on the motor nameplate)
H MOTOR POWER FACTOR 0.1 – 1.0 (printed on the motor nameplate)
I MOTOR BASE FREQ. 30 Hz – 500 Hz (printed on the motor nameplate)
J MOTOR BASE R.P.M. 200 RPM – SYNC. SPEED (printed on the motor nameplate)
K MOTOR NOM. VOLTAGE 110 V – 575 V (printed on the motor nameplate)
