Appendix A – Complete Parameter Settings
A-2 ACH 500 Programming Manual
OPERATING DATA
1 OUTPUT FREQUENCY Hz
2 SPEED RPM; %; USER SCALING
3 MOTOR CURRENT A
4 % RATED TORQUE %
5 % RATED POWER %
6 DC BUS VOLTAGE V; % OF RATED NOMINAL
7 OUTPUT VOLTAGE V
8 DRIVE TEMPERATURE degrees C and F
9 CONTROL LOCATION KEYPAD R1; KEYPAD PI; EXTERNAL
10 KEYPAD REF 1 Hz
11 KEYPAD PI (REF 2) %
12 EXT REF 1 OR 2 REF1/REF2
13 EXTERNAL REF 1 Hz
14 EXTERNAL REF 2 %
15 RUN TIME h/min
16 KILOWATT HOURS kWh
17 LAST-RECD FAULT FAULT; WARNING
18 SECOND-RECD FAULT FAULT; WARNING
19 FIRST-RECD FAULT FAULT; WARNING
20 PARAMETER LOCK OPEN xxx; LOCKED xxx; OPEN; LOCKED
21 APPL BLOCK OUTPUT %
22 ACTUAL VALUE 1 %
23 ACTUAL VALUE 2 %
24 AUX MOTORS RUNNING 0 – 3
25 CONTROLLER OUTPUT %
26 CONTROL ERROR %
27 ACT VALUE 1 (PFC) Engineering Units
28 ACT VALUE 2 (PFC) Engineering Units
Parameter Alternative Settings
