Appendix A – Complete Parameter Settings
ACH 500 Programming Manual A-3
10 CONTROL CONNECTIONS
10.1 START/STOP/DIRECTION
10.1.1 EXT 1 STRT/STP/DIR NOT SEL; DI1; DI1,2; DI1P,2P; DI 1P, 2P, 3; DI1P,2P,3P; DI6; DI6,5;
KEYPAD
10.1.2 EXT 2 STRT/STP/DIR NOT SEL; DI6; DI6,5; DI1; DI1,2; DI1P,2P; DI 1P, 2P, 3; DI1P,2P,3P;
KEYPAD
10.1.3 LOC/EXT DIRECTION REVERSE; FORWARD; REQUEST; FAST REV
10.2 EX REFERENCE SELECT
10.2.1EXT 1/EXT 2 SELECT OP DATA 12; DI1; DI2; DI3; DI4; DI5; DI6
10.2.2 EXTERNAL REF1 SEL OP DATA 13; AI1; AI2; AI1/JOYST; DI3U,4D; DI3U,4D(R); DI5U,6D
10.2.3 EXT REF1 MINIMUM 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.2.4 EXT REF1 MAXIMUM 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.2.5 EXT REF1 OFFSET -30 Hz – 30 Hz
10.2.6 EXT REF1 GAIN -100% – 100 %
10.2.7 EXTERNAL REF2 SEL OP DATA 14; AI1; AI2; DI3U,4D; DI3U,4D(R); DI5U,6D
10.2.8 EXT REF2 MINIMUM 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.2.9 EXT REF2 MAXIMUM 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.2.10 EXT REF2 OFFSET -30 Hz – 30 Hz
10.2.11 EXT REF2 GAIN -100% – 100 %
10.3 PRESET SPEEDS
10.3.1 PRESET SPEED SEL NOT SEL; DI1 – DI6; DI1,2; DI3,4; DI5, 6; DI1,2,3; DI3,4,5; DI4,5,6
10.3.2 PRESET SPEED 1 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.3.3 PRESET SPEED 2 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.3.4 PRESET SPEED 3 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.3.5 PRESET SPEED 4 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.3.6 PRESET SPEED 5 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.3.7 PRESET SPEED 6 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.3.8 PRESET SPEED 7 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
10.4 SYSTEM CONTR INPUTS
Parameter Alternative Settings
Custom
Setting
