Appendix A – Complete Parameter Settings
A-4 ACH 500 Programming Manual
10.4.1 RUN ENABLE YES; DI1; DI2; DI3; DI4; DI5; DI6
10.4.2 FAULT RESET SELECT NOT SEL; DI1; DI2; DI3; DI4; DI5; DI6; ON STOP
10.4.3 PARAM. LOCK SEL OP DATA 20; DI1; DI2; DI3; DI4; DI5; DI6
10.4.4 EXTERNAL FAULT NOT SEL; DI1; DI2; DI3; DI4; DI5; DI6
10.5 ANALOG INPUTS
10.5.1 MINIMUM AI1 0 V/0 mA; 2 V/4 mA; READ INPUT
10.5.2 MAXIMUM AI1 10 V/20 mA; READ INPUT
10.5.3 RC FILTER ON AI1 0.1s – 10s
10.5.4 INVERT AI1 NO; YES
10.5.5 MINIMUM AI2 0 V/0 mA; 2 V/4 mA; READ INPUT
10.5.6 MAXIMUM AI2 10 V/20 mA; READ INPUT
10.5.7 RC FILTER ON AI2 0.1s – 10s
10.5.8 INVERT AI2 NO; YES
10.6 RELAY OUTPUTS
10.6.1 RELAY RO1 OUTPUT NOT USED; READY; RUN; FAULT; FAULT(-1); FAULT(RST)
STALL FLT; MOT OT FLT; OT FAULT; FAULT/WARN; WARNING
OT WARNING; REVERSED; EXT. CTRL; REF 2 SEL; PRESET SPD; DC
BUS LIM; FREQ 1 LIM; FREQ 2 LIM; CURR LIMIT; REF 1 LIMIT; REF 2
LIMIT; AT SPEED; HIGH TEMP; (P&F AUTOM)
10.6.2 RELAY RO2 OUTPUT
10.6.3 RELAY RO3 OUTPUT
10.7 ANALOG OUTPUTS
10.7.1 ANALOG OUTPUT 1 NOT USED; OUT FREQ; MOT SPEED; OUT CURR; MOT TORQ; MOT
POWER; V/DC BUS; MOTOR VOLT; REFERENCE; ERROR VAL; PICON
OUTP; ACTUAL 1; ACTUAL 2; PICON REF
10.7.2 SCALE AO1 10% – 1000%
10.7.3 MINIMUM AO1 0 mA; 4mA
10.7.4 RC FILTER ON AO1 0.01s – 10s
10.7.5 INVERT AO1 NO; YES
10.7.6 ANALOG OUTPUT 2 NOT USED; OUT FREQ; MOT SPEED; OUT CURR; MOT TORQ; MOT
POWER; V/DC BUS; MOTOR VOLT; REFERENCE; ERROR VAL; PICON
OUTP; ACTUAL 1; ACTUAL 2; PICON REF
10.7.7 SCALE AO2 10% – 1000%
10.7.8 MINIMUM AO2 0 mA; 4 mA
10.7.9 RC FILTER ON AO2 0.01s – 10s
10.7.10 INVERT AO2 NO; YES
Parameter Alternative Settings
Custom
Setting
