Appendix B – Programming Digital Inputs
B-2 ACH 500 Programming Manual
* DIx = Any free DI input.
** This selection resets reference value to 0 V if supply voltage is interrupted.
Input function:
0 = open input.
1 = +24 V applied to the input.
10.3 PRESET SPEED SEL
Single speed:
Three speeds:
0 0 No Preset Speed
1 0 Preset Speed 1
0 1 Preset Speed 2
1 1 Preset Speed 3
Seven speeds:
0 0 0 No Preset Speed
1 0 0 Preset Speed 1
0 1 0 Preset Speed 2
1 1 0 Preset Speed 3
0 0 1 Preset Speed 4
1 0 1 Preset Speed 5
0 1 1 Preset Speed 6
1 1 1 Preset Speed 7
DIx*
DI1,2
DI3,4
DI5,6
DI1,2,3
DI3,4,5
DI4,5,6
DI1
DI1
DI1
DI2
DI2
DI2
DI3
DI3
DI3
DI3
DI4
DI4
DI4
DI4
DI5
DI5
DI5
DI5
DI6
DI6
DI6
DI7 DI8 DI9
10.4.1 RUN ENABLE
0 = Disabled, 1 = Run enabled
DIx* DI1 DI2 DI3 DI4 DI5 DI6 DI7 DI8 DI9
10.4.2 FAULT RESET SEL DIx DI1 DI2 DI3 DI4 DI5 DI6 DI7 DI8 DI9
10.4.3 PARAM LOCK SEL DIx DI1 DI2 DI3 DI4 DI5 DI6 DI7 DI8 DI9
20.3.1 ACC/DEC 1 OR 2 SEL DIx DI1 DI2 DI3 DI4 DI5 DI6 DI7 DI8 DI9
Name/Task of Parameter
Parameter
Val ue
Digital I/O Configuration
