28 ACH580 Installation, Operation and Maintenance Manual
ACH580-01 Installation
500…600 volt, fuse requirements
ACH580-01-
Input
current
A
UL
Maximum
current
Voltage
rating
Bussmann type 1 UL class
3-phase UN = 460 V
02A7-6 2.7 15 600 KTK-R-15 or JJS-15 Class CC or T
03A9-6 3.9 15 600 KTK-R-15 or JJS-15 Class CC or T
06A1-6 6.1 15 600 KTK-R-15 or JJS-15 Class CC or T
09A0-6 9 15 600 KTK-R-15 or JJS-15 Class CC or T
011A-6 11 15 600 KTK-R-15 or JJS-15 Class CC or T
017A-6 17 30 600 KTK-R-30 or JJS-30 Class CC or T
022A-6 22 40 600 JJS-40 T
027A-6 27 40 600 JJS-40 T
032A-6 32 40 600 JJS-40 T
041A-6 41 100 600 JJS-100 T
052A-6 52 100 600 JJS-100 T
062A-6 62 100 600 JJS-100 T
077A-6 77 100 600 JJS-100 T
099A-6 99 150 600 JJS-150 T
125A-6 125 200 600 JJS-200 T
144A-6 144 250 600 JJS-250 T
180A-6 180 300 600 JJS-300 T
242A-6 242 400 600 JJS-400 T
271A-6 271 400 600 JJS-400 T
1) ABB does not require Bussmann brand fuses. Fuses which meet the appropriate UL
class type, current rating, and are rated at 600V, 200 kA may be used.
ACH580_Inst_Op_Maint_Rev G.book Page 28
