ABB ACH580-01 - Fuse Specs for 380-480 V Operation

ACH580 Installation, Operation and Maintenance Manual 27
ACH580-01 Installation
380…480 volt, fuse requirements
ACH580-01-
Input
current
A
UL
Maximum
current
Voltage
rating
Bussmann
type 1
UL
class
3-phase UN = 460 V
02A1-4 2.1 15 600 JJS-15 T
03A0-4 3.0 15 600 JJS-15 T
03A5-4 3.5 15 600 JJS-15 T
04A8-4 4.8 15 600 JJS-15 T
07A6-4 7.6 15 600 JJS-15 T
012A-4 12.0 15 600 JJS-15 T
014A-4 14.0 30 600 JJS-30 T
023A-4 23.0 30 600 JJS-30 T
027A-4 27.0 40 600 JJS-40 T
034A-4 34.0 60 600 JJS-60 T
044A-4 44.0 60 600 JJS-60 T
052A-4 52.0 80 600 JJS-80 T
065A-4 62.0 100 600 JJS-100 T
077A-4 77.0 100 600 JJS-100 T
096A-4 100 150 600 JJS-150 T
124A-4 124 200 600 JJS-200 T
156A-4 156 225 600 JJS-225 T
180A-4 180 300 600 JJS-300 T
240A-4 240 350 600 JJS-350 T
302A-4 302 500 600 JJS-500 T
361A-4 361 500 600 JJS-500 T
414A-4 414 600 600 JJS-500 T
1) ABB does not require Bussmann brand fuses. Fuses which meet the
appropriate UL class type, current rating, and are rated at 600V, 200
kA may be used.
