ACS 400 User’s Manual 71
Group 50
COMMUNICATION
5001
DDCS BIT RATE 1, 2, 4, 8 - 1 (1 Mbits/s)
á
5002 DDCS NODE NR 1 - 254 1 1
á
5003 COMM FAULT TIME 0.1 - 60 s 0.1 s 1 s
5004
COMM FAULT FUNC 0 - 3 1 0 (NOT SEL)
5005
PROTOCOL SEL 0 - 3 1 0 (NOT SEL)
á
5006 COMM COMMANDS 0 - 2 1 0 (NOT SEL)
á
5007 DDCS BUS MODE 1 - 2 1 1 (FIELDBUS)
á
5008 DDCS LINK CTRL 0 - 15 1 8
5009
DDCS HW CONFIG 0 - 1 1 0 (RING)
Group 51
EXT COMM MODULE
5101-
5115
FIELDBUSPAR1 - 15 - - -
Group 52
STANDARD MODBUS
5201
STATION NUMBER 1 - 247 1 1
5202
COMM SPEED 3, 6, 12, 24,48, 96, 192 - 96 (9600 bits/s)
5203
PARITY 0 - 2 1 0 (NONE)
5206
BAD MESSAGES 0 - FFFF 1 -
5207
GOOD MESSAGES 0 - FFFF 1 -
5208
BUFFER OVERRUNS 0 - FFFF 1 -
5209
FRAME ERRORS 0 - FFFF 1 -
5210
PARITY ERRORS 0 - FFFF 1 -
5211
CRC ERRORS 0 - FFFF 1 -
5212
BUSY ERRORS 0 - FFFF 1 -
5213
SER FAULT MEM 10 - 255 1 -
5214
SER FAULT MEM 20 - 255 1 -
5215
SER FAULT MEM 30 - 255 1 -
Group 81
PFC CONTROL
8103
REFERENCE STEP 1 0.0 - 100 % 0.1 % 0 %
8104
REFERENCE STEP 2 0.0 - 100 % 0.1 % 0 %
8105
REFERENCE STEP 3 0.0 - 100 % 0.1 % 0 %
8109
START FREQ 1 0.0 - 250 Hz 0.1 Hz 60 Hz
8110
START FREQ 2 0.0 - 250 Hz 0.1 Hz 60 Hz
8111
START FREQ 3 0.0 - 250 Hz 0.1 Hz 60 Hz
8112
LOW FREQ 1 0.0 - 250 Hz 0.1 Hz 30 Hz
8113
LOW FREQ 2 0.0 - 250 Hz 0.1 Hz 30 Hz
8114
LOW FREQ 3 0.0 - 250 Hz 0.1 Hz 30 Hz
8115
AUX MOT START D 0.0 - 3600 s 0.1 s; 1 s 5 s
8116
AUX MOT STOP D. 0.0 - 3600 s 0.1 s; 1 s 3 s
8117
NR OF AUX MOT 0 - 3 1 1
Code Name Range Resolution Default User S M
