CHAPTER 9 – CDP CONTROL PANEL 140
9.6 Parameters mode
9.6.1 Overview
If the parameter lock is disabled or unlocked (see
9.6.3 Enabling / unlocking a parameter lock), the
parameters mode allows entering the parameter
settings for the required drive configuration
depending on the application.
The parameters are organized in functional
groups, so called parameter groups.
When entering the parameters mode for the first
time after the auxiliary supply voltage of the drive
has been switched on, the CDP control panel dis-
plays the first parameter of parameter group 11.
The next time the parameters mode is entered, the
previously selected parameter displays.
Some parameter values cannot be changed while
the drive is running. If tried, the following warning
displays.
Running the drive system with incorrect data can
result in improper operation, reduction of control
accuracy and damage to equipment.
Parameters must only be set by qualified
personnel. Do not change any parameter, if the
meaning of the parameter and the effects of the
change are not fully understood.
Group 07 Control words 21.01 Start function
Group 08 Status words 21.02 Start function
Group 09 Fault and alarm words 21.03 Off1 stop mode
Group 11 Start / stop / direction / MCB control 21.04 Process stop selection
Group 12 Reference selection 21.05 Process stop signal
Group 16 System control inputs 21.06 Process stop MCB control
Group 17 DC-link control 21.07 Process stop mode
Group 18 Utility .
Group 19 Data storage .
Group 20 Limits .
Group 21 Start / stop / process stop 21.17
MCB closing time limi
t
Group 22 Ramp functions 21.17
Group 23 Speed reference 21.19 MCB available signal
For further information on the parame-
ters, their settings and functions, see
Appendix G – Signal and parameter table.
**
WARNING
**
WRITE ACCESS DENIED
PARAMETER SETTING
NOT POSSIBLE
