2.1 Overview
The air-cooled ACS2000 is a general purpose frequency converter for
the control of standard induction motors.
The following drive configurations are described in
this user manual:
• ACS2000 for connection to a non-integrated
transformer
• ACS2000 for connection to an integrated trans-
former (1)
• ACS2000 for direct-to-line connection (DTL)
The following sections provide an overview of:
• the available main and auxiliary power configu-
rations,
• the power electronic components of the drive,
• the cooling system,
• cabinet features such as the grounding switch
and the electro-mechanical door interlock.
For information on the power and voltage
range of the drive, see the technical spec-
ifications and / or the rating plate of the
drive.
