Hardware description
18
9 EMC filter grounding screw (EMC).
10 Varistor grounding screw (VAR)
11 Fieldbus adapter (serial communication module)
connection
12 I/O connections
13 Input power connection (U1, V1, W1), brake resistor
connection (BRK+, BRK-) and motor connection (U2,
V2, W2)
14 Cable glands
1 Cooling element
2 Mounting holes
3 Control Panel
4 Front cover
5 Panel connection
6 Option connection
7 FlashDrop connection
8 Power OK and Fault LEDs
Covers off (R3)Covers on (R3)
4
3
1
2
5
9
7
12
11
10
6
13
8
14
