Technical data
40
Power cable sizes and fuses
See the ACS350 User’s Manual.
Power cables: terminal sizes, maximum cable diameters and tightening
torques
See the ACS350 User’s Manual.
Dimensions, weights and noise
Frame
size
Dimensions and weights Noise
IP66
H1 H2 H3 W D Weight Noise level
mm in. mm in. mm in. mm in. mm in. kg lb dBA
R1 305 12.0 346 13.6 189 7.4 195 7.7 281 11.1 7.7 17.0 <50
R3 436 17.2 477 18.8 300 11.8 246 9.7 277 10.9 13.0 28.7 <50
00353783.xls G
H1 Height from top to bottom
H2 Height from top to bottom with cable glands
H3 Height between mounting brackets
Input power connection
See the ACS350 User’s Manual.
Motor connection
See the ACS350 User’s Manual.
Control connections
See the ACS350 User’s Manual.
Brake resistor connection
See the ACS350 User’s Manual.
Efficiency
See the ACS350 User’s Manual.
Cooling
Method R1 and R3: Internal fan (natural convection cooling).
Free space around the drive See chapter Mechanical installation, page 22.
Degrees of protection
IP66, indoors use only.
