ABB ACS350

Technical data
38
Ratings
Current and power
The current and power ratings are given below. The symbols are described below
the table.
1)
E = EMC filter connected, U = EMC filter disconnected. Metal EMC filter screw is installed in “E”
versions and plastic screw in “U” versions.
Symbols
Type Input Output Frame
size
ACS350…
(+B063)
I
1N
I
2N
I
2,1min/10min
I
2max
P
N
x = E/U
1)
AAAAkWHP
3-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
03x-02A4-2 4.3 2.4 3.6 4.2 0.37 0.5 R1
03x-03A5-2 6.1 3.5 5.3 6.1 0.55 0.75 R1
03x-04A7-2 7.6 4.7 7.1 8.2 0.75 1 R1
03x-06A7-2 11.8 6.7 10.1 11.7 1.1 1.5 R1
03x-07A5-2 12.0 7.5 11.3 13.1 1.5 2 R1
03x-09A8-2 14.3 9.8 14.7 17.2 2.2 3 R3
03x-13A3-2 21.7 13.3 20.0 23.3 3 3 R3
03x-17A6-2 24.8 17.6 26.4 30.8 4 5 R3
3-phase U
N
= 380…480 V (380, 400, 415, 440, 460, 480 V)
03x-01A2-4 2.2 1.2 1.8 2.1 0.37 0.5 R1
03x-01A9-4 3.6 1.9 2.9 3.3 0.55 0.75 R1
03x-02A4-4 4.1 2.4 3.6 4.2 0.75 1 R1
03x-03A3-4 6.0 3.3 5.0 5.8 1.1 1.5 R1
03x-04A1-4 6.9 4.1 6.2 7.2 1.5 2 R1
03x-05A6-4 9.6 5.6 8.4 9.8 2.2 3 R1
03x-07A3-4 11.6 7.3 11.0 12.8 3 3 R1
03x-08A8-4 13.6 8.8 13.2 15.4 4 5 R1
03x-12A5-4 18.8 12.5 18.8 21.9 5.5 7.5 R3
03x-15A6-4 22.1 15.6 23.4 27.3 7.5 10 R3
00353783.xls G
Input
I
1N
continuous rms input current (for dimensioning cables and fuses)
Output
I
2N
continuous rms current. 50% overload is allowed for one minute every ten minutes.
I
2,1min/10min
maximum (50% overload) current allowed for one minute every ten minutes
I
2max
maximum output current. Available for two seconds at start, otherwise as long as
allowed by the drive temperature.
P
N
typical motor power. The kilowatt ratings apply to most IEC 4-pole motors. The
horsepower ratings apply to most NEMA 4-pole motors.
