Mechanical installation
21
Mechanical installation
What this chapter contains
The chapter describes the mechanical installation procedure of the drive.
Unpacking the drive
The package contains the following items:
• (1) ACS350 with IP66 casing and Assistant Control Panel (frame size R3 shown
in the figure)
• (2) user’s manual and (3) IP66 supplement
• mounting template
The package may contain some of the following optional items:
• (4) customizable gland plate (option +H358)
• (5) pressure compensation valve (option +C169)
• (6) Cable Gland Kit (option +H376)
• (7) Input Switch (option +F278)
• other options (such as fieldbus options, instructions for the options).
1
4
2
3
5
6
7
