About the manual
27
Installation and commissioning flowchart
Task See
Identify the frame size of your drive: R1 or R3. Technical data: Ratings on page 50
Plan the installation: select the cables, etc.
Check the ambient conditions, ratings and required
cooling air flow.
Planning electrical installation in the ACS355
user’s manual and Power cable sizes and fuses
on page 52.
Technical data on page 50
Unpack and check the drive. Mechanical installation: Unpacking the drive on
page 34
If the drive will be connected to an IT (ungrounded) or
corner grounded system, check that the internal EMC
filter is not connected.
Hardware description: Type code on page 31
Electrical installation: Connecting the power
cables on page 40
Install the drive on a wall or in a cabinet. Mechanical installation on page 33
Remove the dust protection sticker.
Install the cable glands and route the cables.
Planning electrical installation: Routing the
cables in the ACS355 user’s manual
Check the insulation of the input cable, the motor and
the motor cable.
Electrical installation: Checking the insulation of
the assembly in the ACS355 user’s manual.
Connect the power cables. Electrical installation: Connecting the power
cables on page 40
Connect the control cables. Electrical installation: Connecting the control
cables in the ACS355 user’s manual.
Check the installation and the gaskets. Installation checklist on page 43
Commission the drive. Start-up, control with I/O and ID Run in the
ACS355 user’s manual.
