Technical data
54
Degrees of protection
IP66/67 UL Type 4X, indoor use only.
IP69K with compatible cable glands
Ambient conditions
Environmental limits for the drive are given below. The drive is to be used in a heated
indoor controlled environment.
Operation
installed for stationary use
Storage
in the protective package
Transportation
in the protective package
Installation site altitude 0 to 1000 m (3300 ft) above
sea level
--
Air temperature 0 to +40°C (32 to 104°F).
No
frost allowed. See section
Derating on page 51.
-40 to +70°C (-40 to +158°F) -40 to +70°C (-40 to +158°F)
Relative humidity 0 to 100% Max. 95% Max. 95%
No condensation allowed. Use a pressure compensation valve to avoid condensation (see
Type code on page 31). Maximum allowed relative humidity is 60% in the presence of
corrosive gases.
Contamination levels
(IEC 60721-3-3,
IEC 60721-3-2,
IEC 60721-3-1)
No conductive dust allowed.
According to IEC 60721-3-3,
chemical gases: Class 3C2
solid particles: Class 3S2.
According to IEC 60721-3-1,
chemical gases: Class 1C2
solid particles: Class 1S2
According to IEC 60721-3-2,
chemical gases: Class 2C2
solid particles: Class 2S2
Sinusoidal vibration
(IEC 60721-3-3)
Tested according to
IEC 60721-3-3, mechanical
conditions: Class 3M4
2…9 Hz, 3.0 mm (0.12 in.)
9…200 Hz, 10 m/s
2
(33 ft/s
2
)
--
Shock
(IEC 60068-2-27, ISTA 3A-
Standard)
- According to ISTA 3A-
Standard.
Max. 100 m/s
2
(330 ft/s
2
),
11 ms.
According to ISTA 3A-
Standard.
Max. 100 m/s
2
(330 ft/s
2
),
11 ms.
Free fall Not allowed 76 cm (30 in.) 76 cm (30 in.)
Materials
Drive enclosure •PC
•PC+10%GF
• PC/ABS
•PA66
•TPV
• hot-dip zinc coated steel sheet
• extruded aluminum
• polyester-based powder coating aluminum
• stainless steel
Package Corrugated cardboard.
