ABB ACS355 series - Overview: Connections; Type Code

Hardware description
31
Overview: Connections
See the ACS355 user’s manual.
Type code
The type code contains information on the specifications and configuration of the
drive. You find the type code on the type designation label attached to the drive. The
first digits from the left express the basic configuration, for example ACS355-03E-
08A8-4+B063. The optional selections are given after that, separated by + signs, for
example +K451. The explanations of the type code selections are described below.
ACS355-03E-08A8-4+B063+...
ACS355 product series
01 = 1-phase input
03 = 3-phase input
1-phase/3-phase
In format xxAy, where xx indicates the integer part and y the fractional part,
e.g. 08A8 means 8.8 A.
For more information, see section Ratings on page 50.
Output current rating
2 = 200…240 VAC
4 = 380…480 VAC
Input voltage range
E = EMC filter connected, 50 Hz frequency
U = EMC filter disconnected, 60 Hz frequency
Configuration
C169 = Pressure compensation valve
F278 = Input switch kit
H358 = Customizable gland plate
H376 = Cable gland kit
K451 = FDNA-01 DeviceNet
K454 = FPBA-01 PROFIBUS DP
K457 = FCAN-01 CANopen
K458 = FMBA-01 Modbus RTU
Options
B063 = IP66/67 UL Type 4X, indoor use only. ACS-CP-A Assistant Control Panel
included as standard in delivery. (Area 1: Language support for EN, EN (AM), DE,
IT, ES, PT, NL, FR, DA, FI, SV)
Enclosure variant
