AquaMaster 3
Electromagnetic flowmeter 5 Specification
User Guide OI/FET2XX–EN Rev. E 39
Battery- or renewable energy powered full bore meters – flow specifications
Class 2 specification
DN
Q4 Q3 Q(0.5%) Q2 Q1 R
m
3
/ h
(Ugal / min)
m
3
/ h
(Ugal / min)
m
3
/ h
(Ugal / min)
m
3
/ h
(Ugal / min)
m
3
/ h
(Ugal / min)
25 20 (88) 16 (70) 1.1 (4.83) 0.16 (0.70) 0.10 (0.44) 160
40 50 (220) 40 (176) 2.7 (11.9) 0.4 (1.76) 0.25 (1.10) 160
50 79 (348) 63 (277) 4.2 (18.5) 0.63 (2.77) 0.4 (1.76) 160
65 125 (550) 100 (440) 6.7 (29.5) 1.0 (4.40) 0.63 (2.77) 160
80 200 (880) 160 (704) 10.7 (47.1) 1.6 (7.04) 1.0 (4.40) 160
100 313 (1378) 250 (1100) 16.7 (73.5) 2.5 (11.00) 1.6 (7.04) 160
150 788 (3469) 630 (2733) 42 (184.9) 6.3 (27.73) 3.9 (17.2) 160
200 1,250 (5503) 1,000(4402) 67 (294.9) 10.0 (44.02) 6.3 (27.73) 160
250 2,000 (8805) 1,600 (7044) 107 (471.1) 16.0 (70.44) 10 (44.02) 160
300 3,125 (13759) 2,500 (11007) 167 (735.3) 25.0 (110.07) 15.6 (68.68) 160
