AquaMaster 3
Electromagnetic flowmeter 5 Specification
42 User Guide OI/FET2XX–EN Rev. E
Specification – sensor
Wetted materials
Screw-end meters
Brass and stainless steel 316L
Flanged meters
Electrodes – stainless steel 316L
Potable water approvals
Pressure limitations
As flange rating
PN25 Max Process Temp 50 °C (122 °F)
PN40 Max Process Temp 40 °C (104 °F)
OIML / MID Approved Meters 16 bar (232 psi)
Pressure equipment directive 97/23/EC
This product is applicable in networks for the supply,
distribution and discharge of water and associated
equipment and is therefore exempt.
Environmental Protection
Rating
IP68 (NEMA 6P) to 10 m (33 ft.)
Buriable (sensor only) to 5 m (16 ft.)
Conductivity
>50 µS/cm
End connections
Thread-end connections (MM/GA)
15 mm – ISO 228 G
3
/4 in. B
3
/4 in. NPSM
20 mm – ISO 228 G 1 in. B 1 in. NPSM
25 mm – ISO 228 G 1
1
/4 in. B 1
1
/4 in. NPSM
40 to 300 mm (1.5 to 12 in.) flanged (MM/GA)
EN1092-1 / ISO 7005 – PN10, PN16
ANSI B16.5 Class 150
AS 2129 Tables C, D, E and F
AS 4087 PN14, PN16, PN21
JIS to BS2210, 10k
350 to 600 mm (14 to 24 in.) flanged (MM/GA)
EN1092-1 / ISO 7005 – PN10, PN16
AS 4087 PN14, PN16, PN21
AS 2129 Tables C, D
JIS to B2210 5k and 10k
25 to 300 mm (1 to 12 in.) flanged (MM/GF)
EN1092-1 / ISO 7005 – PN10, PN16
ANSI B16.5 Class 150
AS 4087, PN16
OIML R49 approval (MM/GA only)
Size range and flow specification
See specification table
Accuracy class
1 and 2
Environmental class
T50 0.1 °C to 50 °C (32.18 °F to 122 °F)
Pressure loss class
< 0.63 bar
Minimum upstream pipe
0 D
Minimum downstream pipe
0 D
Orientation
Any
MID Approval
Approved to directive 2004/22/EC
WRAS
Listed
NSF
Approved
ACS
MM/GA  Pending
DN40 to 300,
excluding DN65
and 125
MM/GF  
