ABB AquaMaster 3

AquaMaster 3
Electromagnetic flowmeter 5 Specification
User Guide OI/FET2XX–EN Rev. E 41
AC-powered full bore meters – flow specifications
Class 2 specification
DN
Q
4 Q3 Q(0.25%) Q2 Q1 R
m
3
/ h
(Ugal / min)
m
3
/ h
(Ugal / min)
m
3
/ h
(Ugal / min)
m
3
/ h
(Ugal / min)
m
3
/ h
(Ugal / min)
25 20 (88) 16 (70) 1.6 (7) 0.08 (0.35) 0.05 (0.22) 315
40 50 (220) 40 (176) 4 (17.6) 0.2 (0.88) 0.13 (0.57) 315
50 79 (348) 63 (277) 6.3 (27.7) 0.32 (1.41) 0.20 (0.88) 315
65 125 (550) 100 (440) 10 (44) 0.5 (2.20) 0.32 (1.41) 315
80 200 (880) 160 (704) 16 (70.4) 0.81 (3.56) 0.51 (2.24) 315
100 313 (1378) 250 (1100) 25 (110) 1.3 (5.72) 0.79 (3.47) 315
150 788 (3469) 630 (2733) 63 (277) 3.2 (14.09) 2.0 (8.80) 315
200 1,250 (5503) 1,000(4402) 100 (440) 5.1 (22.45) 3.2 (14.09) 315
250 2,000 (8805) 1,600 (7044) 160 (704) 8.1 (35.66) 5.1 (22.45) 315
300 3,125 (13759) 2,500 (11007) 250 (1100) 12.7 (55.91) 7.9 (34.78) 315
