Aztec 600 aluminium, ammonia, color, iron, manganese, phosphate
Single- and multi-stream colorimetric analyzers 7 Logging
42 IM/AZT6CR–EN Rev. J
7 Logging
Data recorded in the analyzer's internal memory can be archived
to a removable Secure Digital (SD) card media. The analyzer
records all data continuously to its internal memory and keeps
track of which data has been archived.
Sample data can be saved to removable media as either
binary-encoded or comma-separated files.
Additional files can also be archived:
Alarm event log data
Audit log data
Configuration files
Screen capture images
Fig. 7.1 Recording and Archiving
Invalid
Password
Valid
Password
No Password
Required
Password
Required
(if set)
Resets Archiving – see Section 7.2, page 44
Switches the removable media online/offline
Opens the file viewer – see Section 7.3, page 44
On-line help – see Section 3.2, page 11
Note. ABB’s DataManager software can be used to store
and view data archived from the analyzer.
Caution. Electrostatic precautions for SD cards.
To avoid potential damage or corruption to data recorded on
an SD card, take care when handling and storing the card. Do
not expose the card to static electricity, electrical noise or
magnetic fields. When handling the card take care not to
touch any exposed metal contacts.
