Aztec 600 aluminium, ammonia, color, iron, manganese, phosphate
Single- and multi-stream colorimetric analyzers 14 Specification
76 IM/AZT6CR–EN Rev. J
Mechanical Data
Ingress protection
Sample connections
Dimensions
Materials of construction
Electrical
Supply ranges
100 to 240 V max. AC 50/60 Hz ± 10 % (90 to 264 V AC, 45/65 Hz)
18 to 36 V DC (optional)
Power consumption
75 W max. – AC
100 W max. – DC
Analog Outputs
Single and multi-stream analyzers
6 isolated current outputs, fully assignable and programmable over a
0 to 20 mA range (up to 22 mA if required)
Alarms/Relay Outputs
Single- and multi-stream analyzers
One per unit:
Stop relay
Attention relay
Failure relay
Calibrate relay
Six per unit:
Fully user-assignable alarm relays
Rating
*Not evaluated for UL or CB
Connectivity/Communications
Ethernet connection
Bus communications
Profibus DP V1.0 (optional)
Data Handling, Storage and Display
Security
Storage
Removable Secure Digital (SD) card
Trend analysis
Local and remote
Data transfer
SD card or FTP
Approvals, Certification and Safety
Safety Approval
cULus
CE Mark
Covers EMC & LV Directives (including latest version EN 61010)
General Safety
EN 61010–1
Overvoltage Class 11 on inputs and outputs
Pollution category 2
EMC
Emissions & immunity
Meets requirements of IEC61326 for an Industrial Environment
DS/AZT6AL–EN Rev. F
DS/AZT6AM–EN Rev. C
DS/AZT6C–EN Rev. B
DS/AZT6IR–EN Rev. H
DS/AZT6ML–EN Rev. C
DS/AZT6MN–EN Rev. D
DS/AZT6P–EN Rev. D
IP31*
Inlet: 6 mm OD push-fit x
1
/4 in BSP elbow
Outlet: 10 mm OD push-fit x
3
/8 in BSP elbow
Height 653 mm (25.7 in)
Width 366 mm (14.4 in) max.
Depth 183 mm (7.2 in) door closed
430 mm (16.9) door open
Weight 15 kg (33 lb)
Electronics enclosure 10 % glass loaded polycarbonate
Main enclosure Noryl
Lower tray 20 % glass loaded polypropylene
Door Acrylic
Voltage 250 V AC 30 V DC
Current 5 A AC 5 A DC
Loading (non-inductive) 1250 VA 150 W
Web server with ftp For real-time monitoring, configuration,
data file access and e-mail capability
Multi level security Operator and configuration
Password or security switch
