ABB ControlMaster CM50 User Manual

ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 4 Installation
10 IM/CM/S–EN Rev. R
Dimensions in mm (in.)
Fig. 4.3 ControlMaster CM50 Dimensions
Controllers can be
close-stacked to
DIN 43835
144
(5.67)
123 (4.84)
146 (5.74)
138
(5.43)
23 (0.9)
138
(5.43)
30 (1.18)
14 (0.55)
(+0.04 –0)
+1.0 –0
68 +0.7
–0
(2.67 +0.03
–0
)
76 (3.0)
