ABB ControlMaster CM50 User Manual

ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 3 Displays, Icons and Keys
6 IM/CM/S–EN Rev. R
3.2 CM30 and CM50 Operator Page, Icons & Keys
The ControlMaster CM30 and CM50 displays and icons are shown in Fig. 3.2.
Fig. 3.2 ControlMaster CM30 and CM50 Displays and Icons
CM50
1000.0
0.0
479.2
500.0
74.9
AUTO
LOCAL
PSI
PV
SP
OP
ControlMaster
CM30
PSI
PV
SP
OP
ControlMaster
479.2
500.0
74.9 %
PV Value
Bargraph
Setpoint
Value
Icons
Access
Level
Manual
Mode
Local Setpoint
Remote
Setpoint
Output
Value
Auto
Mode
Operator
Level
Menu
Icons
Adjust
– Indicates which value is adjusted
by the / keys
Process
Alarm
Autotune
