ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 5 Operator Level Menus
24 IM/CM/S–EN Rev. R
5.1 Diagnostic Status Bar
Fig. 5.1 ControlMaster Diagnostic Status Bar (ControlMaster CM30 Shown)
PV 1 Failed
ControlMaster
PV
SP
99.5
175.0
32.5
OP
deg C
%
PV 1 Failed
Description of diagnostic
or alarm tag.
The highest priority diagnostic or
alarm is displayed. Other active
diagnostic / alarm states can be
viewed on the Diagnostic View –
see page 25.
Failure
Maintenance
Out of Spec
Check Function
NAMUR (NE107) Status Icon
High Process Alarm
Low Process Alarm
High Latch Alarm
Low Latch Alarm
