ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
IM/CM/S–EN Rev. R 39
7.2 Display
Used to setup the operator page, displayed language and display hardware settings.
Language Selects the language on the controller's local display.
Operator Templates Enables up to 4 operator pages to be configured to suit the application requirements.
Page 1 (4) Template The operator template type. The functions available in each template type are displayed as
abbreviations, for example:
Single PV, SP & OP
Key to abbreviations:
PV = process variable
SP = setpoint
MOP = master output (Auto/Manual [see page 40] status and analog backups)
OP = control output
Loop 1 (2) = displays PV, SP and SP for Loop 1 (2)
AR = actual ratio
DR = desired ratio
