DCS500 Pin and Parameter list
A 6
Maximum HL = high level; is given as internal values
Minimum LL = low level; is given as internal values
Default is given as internal values
Unit either the maximum or the minimum or the default value has to be multiplied
by the scaling factor; then the unit has to be added to that number to get the
physical value
Example: The parameter which is defining nominal voltage of the motor has following
description:
U_MOTN_V
Parameter of SETTINGS-function block (S2/16 | mod in S21.232)
The nominal voltage of the motor in volts. (higher HL in S21.232)
501 FB_P: I2 SC: 1 HL: 1800 LL: 0 D: 0 U: V
Name U_MOTN_V
Para will be found at the SETTINGS function block, which is shown on the
software diagrams on page 2 out of 16; this parameter has been modified at
software version S21.232 and has still this new function
Expl description in verbal form
Index parameter group = 5, element = 01
Data type FB_P: Parameter of a function block
I2 16-bit signed integer
Scaling factor equal 1
Maximum 1800
Minimum 0
Default 0 (at C1, C2, C3: will be set by the converter automatically)
Unit is Volt; example: HL (= 1800) * SC (= 1) = 1800V
