ABB DCS 500B

DCS500 Pin and Parameter list
A 23
Group 6: DATA LOGGER
DLOG.[IN1]
Input of DATA_LOGGER-function block. ( S14/16 )
Selects the signal which is measured in channel 1.
601 FB_I: C4 SC: - HL: 19999 LL: 0 D: 12102 U: -
DLOG.[IN2]
Input of DATA_LOGGER-function block. ( S14/16 )
Selects the signal which is measured in channel 2.
602 FB_I: C4 SC: - HL: 19999 LL: 0 D: 10501 U: -
DLOG.[IN3]
Input of DATA_LOGGER-function block. ( S14/16 )
Selects the signal which is measured in channel 3.
603 FB_I: C4 SC: - HL: 19999 LL: 0 D: 10505 U: -
DLOG.[IN4]
Input of DATA_LOGGER-function block. ( S14/16 )
Selects the signal which is measured in channel 4.
604 FB_I: C4 SC: - HL: 19999 LL: 0 D: 10504 U: -
DLOG.[IN5]
Input of DATA_LOGGER-function block. ( S14/16 )
Selects the signal which is measured in channel 5.
605 FB_I: C4 SC: - HL: 19999 LL: 0 D: 11302 U: -
DLOG.[IN6]
Input of DATA_LOGGER-function block. ( S14/16 )
Selects the signal which is measured in channel 6.
606 FB_I: C4 SC: - HL: 19999 LL: 0 D: 10401 U: -
DLOG.TRIGG_COND
Parameter of DATA_LOGGER-function block. ( S14/16 )
Selects the triggering condition for the data logger:
0 = EXTERNAL
1 = FAULT or EXT
2 = DIFFERENCE
3 = MAX
4 = MIN
607 FB_P: E2 SC: - HL: 4 LL: 0 D: 1 U: -
DLOG.TRIGG_VALUE
Parameter of DATA_LOGGER-function block. ( S14/16 )
Reference value that will be used if the trigger condition DLOG.TRIGG_CONT is set to
DIFFERENCE, MAX or MIN
608 FB_P: I2 SC: - HL: 32767 LL: -32768 D: 20000 U: -
DLOG.TRIGG_DELAY
Parameter of DATA_LOGGER-function block. ( S14/16 )
Number of samples collected after triggering instant. Length of data logger is 1000
samples in each channel.
609 FB_P: I2 SC: - HL: 1000 LL: 0 D: 200 U: -
DLOG.SAMPL_INT
Parameter of DATA_LOGGER-function block. ( S14/16 )
Sampling interval defining how often a measurement is made in each channel.
610 FB_P: I2 SC: 1 HL: 1000 LL: 1 D: 3 U: ms
