ABB DCS 500B

DCS500 Pin and Parameter list
A 33
Group 11: FAULTS, ALARMS
USER_EVENT1.[IN]
Input of EVENT1-function block. ( S15/16 )
Activates logging of an external alarm or fault into the Fault Logger.
1101 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
USER_EVENT1.TYPE
Parameter of EVENT1-function block. ( S15/16 )
Selects the type of external event:
0 = FAULT:TRIPLEVEL 1 (main, field and fan contactors are opened)
1 = FAULT:TRIPLEVEL 2 (main and field contactors are opened)
2 = FAULT:TRIPLEVEL 3 (main contactor is opened)
3 = ALARM: (only alarm indication)
4 = EVENT: (only logging to Fault Logger).
1102 FB_P: E2 SC: - HL: 4 LL: 0 D: 0 U: -
USER_EVENT1.TEXT
Parameter of EVENT1-function block. ( S15/16 )
This parameter shows the event´s name: EXT. IND. 1
1103 FB_P: - SC: - HL: - LL: - D: - U: -
USER_EVENT1.DLY
Parameter of EVENT1-function block. ( S15/16 )
Selects the activation delay.
External event has to be active for longer than the activation delay until it is accepted.
1104 FB_P: I2 SC: 0.01 HL: 32767 LL: 0 D: 0 U: s
USER_EVENT2.[IN]
Input of EVENT2-function block. ( S15/16 )
Activates logging of an external alarm or fault into the Fault Logger.
1105 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
USER_EVENT2.TYPE
Parameter of EVENT2-function block. ( S15/16 )
Selects the type of external event:
(see USER_EVENT1.TYPE for available values).
1106 FB_P: E2 SC: - HL: 4 LL: 0 D: 0 U: -
USER_EVENT2.TEXT
Parameter of EVENT2-function block. ( S15/16 )
This parameter shows the event´s name: EXT. IND. 2
1107 FB_P: - SC: - HL: - LL: - D: - U: -
USER_EVENT2.DLY
Parameter of EVENT2-function block. ( S15/16 )
Selects the activation delay.
External event has to be active for longer than the activation delay until it is accepted.
1108 FB_P: I2 SC: 0.01 HL: 32767 LL: 0 D: 0 U: s
USER_EVENT3.[IN]
Input of EVENT3-function block. ( S15/16 )
Activates logging of an external alarm or fault into the Fault Logger.
1109 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
USER_EVENT3.TYPE
Parameter of EVENT3-function block. ( S15/16 )
Selects the type of external event:
(see USER_EVENT1.TYPE for available values).
1110 FB_P: E2 SC: - HL: 4 LL: 0 D: 0 U: -
