ABB DCS 500B

DCS500 Pin and Parameter list
A 34
USER_EVENT3.TEXT
Parameter of EVENT3-function block. ( S15/16 )
This parameter shows the event´s name: EXT. IND. 3
1111 FB_P: - SC: - HL: - LL: - D: - U: -
USER_EVENT3.DLY
Parameter of EVENT3-function block. ( S15/16 )
Selects the activation delay.
External event has to be active for longer than the activation delay until it is accepted.
1112 FB_P: I2 SC: 0.01 HL: 32767 LL: 0 D: 0 U: s
USER_EVENT4.[IN]
Input of EVENT4-function block. ( S15/16 )
Activates logging of an external alarm or fault into the Fault Logger.
1113 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
USER_EVENT4.TYPE
Parameter of EVENT4-function block. ( S15/16 )
Selects the type of external event:
(see USER_EVENT1.TYPE for available values).
1114 FB_P: E2 SC: - HL: 4 LL: 0 D: 0 U: -
USER_EVENT4.TEXT
Parameter of EVENT4-function block. ( S15/16 )
This parameter shows the event´s name: EXT. IND. 4
1115 FB_P: - SC: - HL: - LL: - D: - U: -
USER_EVENT4.DLY
Parameter of EVENT4-function block. ( S15/16 )
Selects the activation delay.
External event has to be active for longer than the activation delay until it is accepted.
1116 FB_P: I2 SC: 0.01 HL: 32767 LL: 0 D: 0 U: s
USER_EVENT5.[IN]
Input of EVENT5-function block. ( S15/16 )
Activates logging of an external alarm or fault into the Fault Logger.
1117 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
USER_EVENT5.TYPE
Parameter of EVENT5-function block. ( S15/16 )
Selects the type of external event:
(see USER_EVENT1.TYPE for available values).
1118 FB_P: E2 SC: - HL: 4 LL: 0 D: 0 U: -
USER_EVENT5.TEXT
Parameter of EVENT5-function block. ( S15/16 )
This parameter shows the event´s name: EXT. IND. 5
1119 FB_P: - SC: - HL: - LL: - D: - U: -
USER_EVENT5.DLY
Parameter of EVENT5-function block. ( S15/16 )
Selects the activation delay.
External event has to be active for longer than the activation delay until it is accepted.
1120 FB_P: I2 SC: 0.01 HL: 32767 LL: 0 D: 0 U: s
USER_EVENT6.[IN]
Input of EVENT6-function block. ( S15/16 )
Activates logging of an external alarm or fault into the Fault Logger.
1121 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
