ABB DCS 500B

DCS500 Pin and Parameter list
A 8
Group 1: ANALOG INPUTS
AITAC_CONV_MODE
Parameter of AITAC-function block ( S4/16 )
Selector for type of input signal:
0 = DISABLE channel not in use
1 = +/-10V OR +/-20 mA -10...+10V IOB3
-20...+20mA IOB3: S1:1-2 connected
2 = 4...20 mA 4 ... 20mA IOB3: S1:1-2 connected
3 = TACHO VOLT. +/-10V 90...270V IOB1, CON-2: X3:1-4:
30... 90V IOB1, CON-2: X3:2-4:
0 ... 30V IOB1, CON-2: X3:3-4:
101 FB_P: E2 SC: - HL: 3 LL: 0 D: 0 U: -
AITAC_HIGH_VALUE
Parameter of AITAC-function block ( S4/16 ).
Value that corresponds to upper range input signal (+10V/20mA)
102 FB_P: I2 SC: SPEED HL: 32767 LL: -32768 D: 30000 U: rpm
AITAC_LOW_VALUE
Parameter of AITAC-function block ( S4/16 ).
Value that corresponds to lower range input signal (-10V/0mA/4mA)
103 FB_P: I2 SC: SPEED HL: 32767 LL: -32768 D: -30000 U: rpm
AI1_CONV_MODE
Parameter of AI1-function block ( S4/16 ).
Selector for type of input signal:
0 = DISABLE, channel not in use
1 = +/-10V OR +/-20 mA -10...+10V IOB1, IOB3, CON-2
-20...+20mA IOB1, CON-2: 500 ohms between X3:5-6
IOB3: S1:3-4 connected
2 = 4...20 mA 4 ... 20mA IOB1, CON-2: 500 ohms between X3:5-6
IOB3: S1:3-4 connected
104 FB_P: E2 SC: - HL: 2 LL: 0 D: 1 U: -
AI1_HIGH_VALUE
Parameter of AI1-function block ( S4/16 ).
Value that corresponds to upper range input signal (+10V/20mA)
105 FB_P: I2 SC: SPEED HL: 32767 LL: -32768 D: 20000 U: rpm
AI1_LOW_VALUE
Parameter of AI1-function block ( S4/16 ).
Value that corresponds to lower range input signal (-10V/0mA/4mA)
106 FB_P: I2 SC: SPEED HL: 32767 LL: -32768 D: -20000 U: rpm
