ABB DCS 500B

DCS500 Pin and Parameter list
A 108
Group 123: TORQUE and CURRENT LIMITS
SPC_TORQMAX1
Signal of TORQUE/CURRENT LIMITATION-function block. ( S6/16 )
Positive torque limit for speed controller.
12301 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
SPC_TORQMIN1
Signal of TORQUE/CURRENT LIMITATION-function block. ( S6/16 )
Negative torque limit for speed controller.
12302 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
TREF_TORQMAX1
Signal of TORQUE/CURRENT LIMITATION-function block. ( S6/16 )
Positive torque limit for torque reference chain.
12303 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
TREF_TORQMIN1
Signal of TORQUE/CURRENT LIMITATION-function block. ( S6/16 )
Negative torque limit for torque reference chain.
12304 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
TORQMAX2
Signal of TORQUE/CURRENT LIMITATION-function block. ( S6/16 )
Positive torque limit before external torque limitation.
12305 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
TORQMIN2
Signal of TORQUE/CURRENT LIMITATION-function block. ( S6/16 )
Negative torque limit before external torque limitation.
12306 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
CURR_LIM_P
Signal of TORQUE/CURRENT LIMITATION-function block. ( S6/16 )
Positive current limit for current contoller.
12307 FB_O: I2 SC:MCURR HL: - LL: - D: - U: A
CURR_LIM_N
Signal of TORQUE/CURRENT LIMITATION-function block. ( S6/16 )
Negative current limit for current contoller.
12308 FB_O: I2 SC:MCURR HL: - LL: - D: - U: A
