ABB DCS 500B

DCS500 Pin and Parameter list
A 25
Group 8: DIGITAL OUTPUTS
DO1.[IN]
Input of DO1-function block. ( S3/16 )
Normal input.
801 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 10908 U: -
DO1.[INV_IN]
Input of DO1-function block. ( S3/16 )
Inverted input.
802 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
DO2.[IN]
Input of DO2-function block. ( S3/16 )
Normal input.
803 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 10909 U: -
DO2.[INV_IN]
Input of DO2-function block. ( S3/16 )
Inverted input.
804 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
DO3.[IN]
Input of DO3-function block. ( S3/16 )
Normal input.
805 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 10910 U: -
DO3.[INV_IN]
Input of DO3-function block. ( S3/16 )
Inverted input.
806 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
DO4.[IN]
Input of DO4-function block. ( S3/16 )
Normal input.
807 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 10902 U: -
DO4.[INV_IN]
Input of DO4-function block. ( S3/16 )
Inverted input.
808 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
DO5.[IN]
Input of DO5-function block. ( S3/16 )
Normal input.
809 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 10903 U: -
DO5.[INV_IN]
Input of DO5-function block. ( S3/16 )
Inverted input.
810 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
DO6.[IN]
Input of DO6-function block. ( S3/16 )
Normal input.
811 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
DO6.[INV_IN]
Input of DO6-function block. ( S3/16 )
Inverted input.
812 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
