ABB DCS 500B

DCS500 Pin and Parameter list
A 105
Group 120: SPEED CONTROLLER
ERR:OUT
Signal of SPEED_ERROR-function block ( S5/16 )
Speed error which is usually connected to the speed controller input.
12001 FB_O: I2 SC: SPEED HL: - LL: - D: - U: rpm
ERR:OUT_OF_WIN
Signal of SPEED_ERROR-function block ( S5/16 )
Indication which is active when speed error is out of error window ERR.WIN_SIZE (2004).
12002 FB_O: B SC: BO HL: - LL: - D: - U: -
ERR:STEP_RESP
Signal of SPEED_ERROR-function block ( S5/16 )
Speed error output which is used to show the behaviour of speed controller in step
response test.
12003 FB_O: I2 SC: SPEED HL: - LL: - D: - U: rpm
SPC:OUT
Signal of SPEED_CONTROL-function block ( S5/16 )
Torque reference output from speed controller.
12004 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
SPC:IN_LIM
Signal of SPEED_CONTROL-function block ( S5/16 )
Indication from speed controller showing that output is in limit.
12005 FB_O: B SC: BO HL: - LL: - D: - U: -
