ABB DCS 500B

DCS500 Pin and Parameter list
A 55
Group 22: SPEED MONITOR
MIN_SPEED_L
Parameter of SPEED_MONITOR-function block. ( S5/16 )
Limit value for minimum speed detection.
When speed is below this limit MIN_SPEED (12201) output of the function block is set.
2201 FB_P: I2 SC: SPEED HL: 30000 LL: 0 D: 50 U: rpm
SPEED_L1
Parameter of SPEED_MONITOR-function block. ( S5/16 )
Limit value for speed level detection. When speed is above this limit SPEED_GT_L1
(12202) output of the function block is set.
2202 FB_P: I2 SC: SPEED HL: 30000 LL: 0 D: 5000 U: rpm
SPEED_L2
Parameter of SPEED_MONITOR-function block. ( S5/16 )
Limit value for speed level detection. When speed is above this limit SPEED_GT_L2
(12203) output of the function block is set.
2203 FB_P: I2 SC: SPEED HL: 30000 LL: 0 D: 10000 U: rpm
OVERSPEEDLIMIT
Parameter of SPEED_MONITOR-function block. ( S5/16 )
Limit value for overspeed detection. When speed is above this limit OVERSPEED (12204)
output of the function block is set an the drive will trip.
2204 FB_P: I2 SC: SPEED HL: 30000 LL: 0 D: 23000 U: rpm
STALL.SEL
Parameter of SPEED_MONITOR-function block. ( S5/16 )
Selection parameter for stall protection:
0 = DISABLED
1 = ENABLED.
2205 FB_P: E2 SC: - HL: 1 LL: 0 D: 0 U: -
STALL.SPEED
Parameter of SPEED_MONITOR-function block. ( S5/16 )
Speed limit value for stall detection.
When speed is below this limit and torque is higher than STALL.TORQUE for a time longer
than STALL.TIME, the drive will trip.
2206 FB_P: I2 SC: SPEED HL: 20000 LL: 0 D: 50 U: rpm
STALL.TORQUE
Parameter of SPEED_MONITOR-function block. ( S5/16 )
Torque limit value for stall detection. Description see STALL.SPEED (2206).
2207 FB_P: I2 SC: TORQ HL: 16000 LL: 0 D: 3000 U: %
STALL.TIME
Parameter of SPEED_MONITOR-function block. ( S5/16 )
Time delay for stall detection. Description see STALL.SPEED (2206).
2208 FB_P: I2 SC: 1 HL: 180 LL: 1 D: 10 U: s
MON.MEAS_LEV
Parameter of SPEED_MONITOR-function block. ( S5/16 )
This function is comparing speed actual from pulse or analog tacho and the calculated
EMF_ACT (10506) of the motor. If speed measurement fails the speed is zero, but the
EMF_ACT (10506) will increase when the drive is started.
MON.MEAS_LEV is the minimum absolute value the measured speed must have when
EMF_ACT (10506) is over the limit MON.EMF_V. Otherwise the drive trips to the speed
measurement fault.
2209 FB_P: I2 SC: SPEED HL: 20000 LL: 0 D: 200 U: rpm
