ABB DCS 500B

DCS500 Pin and Parameter list
A 10
AI4_CONV_MODE
Parameter of AI4-function block (S11/16 ).
Selector for type of input signal:
0 = DISABLE channel not in use
1 = +/-10V or +/-20 mA -10...+10V IOB1, CON-2
IOB3: S1:11-12, 13-14 not connected.
-20...+20mA IOB1, CON-2: 500 ohms between X4:1-2
IOB3: S1:9-10 connected
S1:11-12, 13-14 not connected.
2 = 4...20 mA 4 ... 20mA IOB1, CON-2: 500 ohms between X4:1-2
IOB3: S1:9-10 connected
S1:11-12, 13-14 not connected
3 = EARTH FAULT MON. IOB3: S1:9-10 not connected
S1:11-12, 13-14 connected
connection terminals: X3:11, 12
113 FB_P: E2 SC: - HL: 3 LL: 0 D: 0 U: -
AI4_HIGH_VALUE
Parameter of AI4-function block (S11/16 ).
Value that corresponds to upper range input signal (+10V/20mA)
114 FB_P: I2 SC: 1 HL: 32767 LL: -32768 D: 2000 U: -
AI4_LOW_VALUE
Parameter of AI4-function block (S11/16 ).
Value that corresponds to lower range input signal (-10V/0mA/4mA)
115 FB_P: I2 SC: 1 HL: 32767 LL: -32768 D: -2000 U: -
AI5_CONV_MODE
Parameter of AI5-function block (S11/16 ).
Selector for type of input signal:
0 = DISABLE channel not in use
1 = +/-10V or +/-20 mA -10...+10V SDCS-IOE-1
-20...+20mA SDCS-IOE-1: S1: 3-4 connected
2 = 4...20 mA 4 ... 20mA SDCS-IOE-1: S1: 3-4 connected
116 FB_P: E2 SC: - HL: 2 LL: 0 D: 0 U: -
AI5_HIGH_VALUE
Parameter of AI5-function block (S11/16 ).
Value that corresponds to upper range input signal(+10V/20mA)
117 FB_P: I2 SC: 1 HL: 32767 LL: -32768 D: 2000 U: -
AI5_LOW_VALUE
Parameter of AI5-function block (S11/16 ).
Value that corresponds to lower range input signal (-10V/0mA/4mA)
118 FB_P: I2 SC: 1 HL: 32767 LL: -32768 D: -2000 U: -
AI6_CONV_MODE
Parameter of AI6-function block (S11/16 ).
Selector for type of input signal:
0 = DISABLE channel not in use
1 = +/-10V or +/-20 mA -10...+10V SDCS-IOE-1
-20...+20mA SDCS-IOE-1: S2: 3-4 connected
2 = 4...20 mA 4 ... 20mA SDCS-IOE-1: S2: 3-4 connected
119 FB_P: E2 SC: - HL: 2 LL: 0 D: 0 U: -
AI6_HIGH_VALUE
Parameter of AI6-function block (S11/16 ).
Value that corresponds to upper range input signal (+10V/20mA)
120 FB_P: I2 SC: 1 HL: 32767 LL: -32768 D: 2000 U: -
