ABB DCS 500B

DCS500 Pin and Parameter list
A 13
DATASET4.[IN1]
Input of DATASET4 function block ( S12/16 )
DATASET 4 is used for data transmission from the drive to the fieldbus master.
When a fieldbus communication module is connected the DCS 500 can transmit a
3 word telegram called DATASET4.[IN1]…[IN3] to a fieldbus master.
DATASET4.[IN1] selects the address of first word of this telegram.
212 FB_I: C4 SC: - HL: 19999 LL: 0 D: 0 U: -
DATASET4.[IN2]
Input of DATASET4 function block ( S12/16 )
DATASET4.[IN2] selects the address of second word of this telegram.
213 FB_I: C4 SC: - HL: 19999 LL: 0 D: 0 U: -
DATASET4.[IN3]
Input of DATASET4 function block ( S12/16 )
DATASET4.[IN3] selects the address of third word of this telegram.
214 FB_I: C4 SC: - HL: 19999 LL: 0 D: 0 U: -
